Guide To Setting Up A New Veeam Replication Job

Written by Allen White on. Posted in Veeam, VMware

This guide will show you step by step on how to setup a new replication job in Veeam, click here to setup a backup job in Veeam.Or even here if you need to install Veeam. A replication works by taking a snapshot of the virtual machine in vmware then replicating the machine to another host or cluster. In the example I will show you my environment has a 3 host cluster and a single vsphere host that is not in any cluster or managed by a VC. The plan is to first add the virtual center server in the cluster to Veeam, then the single host to the Veeam setup. We will then replicate certain servers from the cluster to the single host which is situated off site.

Add A Host Or VC to Veeam

First we need to launch Veeam and add our virtual center server and  our single host.To do this select  infrastructure.

veeam infrastructure

Under managed servers expand VMware vSphere and right click vCenter Servers. Once done select Add Server. Repeat the process for adding a standalone host but select “Standalone Hosts” rather than vCentre Server.

add virtual centre to veeam

add virtual centre to veeam

You now get prompted to add your virtual center server/host. Simply enter the servers hostname then select next.

setup a veeam replication virtual centre

setup a veeam replication virtual centre

Then, enter your DOMAIN CREDENTIALS to authenticate to the virtual center server. If the VC is in a work group then enter the local computer accounts credentials.

domain credentials for veeam virtual centre

domain credentials for veeam virtual centre



Then , finally accept the summary and you will see the VC added to managed servers.

vc added to veeam

vc added to veeam

Go through the process again to add either your second VC of your DR host. You will then see both under managers servers. We are now ready to setup the Veeam Replication job.

Setting Up A Veeam Replication Job

To start we need to select the backup and replication tab. Do so.

veeam backup and replication

veeam backup and replication

Then under Backup and Replication and expand jobs and right click replication and select replication job.

Setup a replication job in veeam

Setup a replication job in veeam

Enter a valid name for your replication job and then select next.

Setup DR replication in Veeam

Setup DR replication in Veeam

Then, on the right hand side of the next screen select Add. You can then expand to your virtual center and select to servers you would like to replicate. You can see I have added my servers here.add-servers-to-Veeam-Replication-Job.

If on some of your servers you do not wish te replicate all of the drives on that server to save space. simply select a server then select exclusions. You can then exclude your drives. If you are unsure what the drives are. In virtual center right click the server, select hard drives and you will be able to see the scsi ID to tally up what drive is what.

Veeam-disk-exclusions

The next section is quite important. You get the option to choose your DR host, if you have one a resource pool and the datastore on the DR host.

selecting DR host in veeam

selecting DR host in veeam

Under host and cluster, click Choose and browse to the DR host you added to the managed servers section earlier.Then select ok.

Veeam choosing a DR host

Veeam choosing a DR host

If you have a resource pool on your DR host then again select it, I’m just using the default pool here. Again the same for folders of you have them defined, I do not. Then finally select the datastore you would like to replicate to. If you have multiple datastores then it may be an idea to have multiple replication jobs the replicate to multiple stores.Once you have chosen your options click next.

On the Job settings screen that follows leave the settings of automatic proxy enabled unless you have a specific backup proxy server setup. You get the option to select a repository for the backups metadata, I have a NAS box so im using it, you can just use the default setting that is the clusters datastore. The replica name suffix is what the replicated servers have as a suffix on the DR host. For example ALLENSERVER on the cluster would become ALLENSERVER_replica.

Restore points is as it says , how many replications would you like to be able to go back to.

The next screen is for VSS, pop in your domains admin credentials, this allows veeam to lo-gin to VSS aware applications such as SQL and Exchange. If you are using any of these applications then enter the information here. Then select next.

veeam-application-aware-settings

Then next screen is fairly self explanatory. Set your schedule of when you would like the veeam replication to take place. If you have the network bandwidth there is no reason to not run it continuously, that means in the event of a failure you will have lost the least amount of data.Click next.

setup veeam schedule

setup veeam schedule

You will see the summary screen. Pop a tick in replication to start now and the job will run. If not wait until your schedule begins. Once it has completed it will look like this.

veeam-hosts-replicated

As you can see the servers have replicated and the suffix has been added.

Veeam Controlled Fail Over

The article was originally written for a project I was on, however  Shane Williford (@coolsport00 – see comments) came up with a valid point.If you are also replicating your Veeam server the correct way to failover to your replicas is as follows.

Launch the Veeam Backup and replication app. Then browse down to replicas. You will see a status of ready. This means that replicas are in place and ready to fail over if required.

Veeam-failover

To fail over, select the servers you want to recover, then right click and select fail over.

failover-of-site-in-veeam

Click the next screen to confirm and you will then need to give a reason for the fail over.

test veeam failover

test veeam fail over

The server/servers will then start the fail over to the replica. You can see the job becomes active and will update you on its status.

Veam-resotre-replicas

Once complete, you will see that under active the server has failed over to the DR host. Now providing all your vswitches are setup correctly the vm should run fine and connectivity will be restored.

Once the cluster is back up and running you have two options, you can undo the fail over, which switches the server back to the VM managed by vcentre and sets the vm on the DR host back to the replica and turns it off.

revert failover status in veeam

revert failover status in veeam

The alternative is to “Fallback to Production”. Ive left the screenshot full screen here as the descriptions of each option save me a job.The main differences being you may be restoring to a new datastore or the original VM is not available to fallback to.

Fallback to production

Fallback to production



Again thanks to Shane Williford for picking me up on the failover options.
